15HP Walking Tractor, 15HP Hand Tractor, Heavy Duty 2 Wheel Tractor
Go back to Catalog: Walking Tractor
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
15HP Walking Tractor Series
Heavy Duty Hand Tractors, Walk Behind Tractor 15 HP Walking Tractor with Loncin Engine
Overall Dimension(mm) 2170× 930× 1150
Ground Clearance(mm) 210
Engine ZH1100
Power 15 HP
Wheelbase(mm) 680~1200
Weight(kg) 370
Semiaxis cm 520-600
Weight in use(with oil, water, tools) (kg) 430
Tyre Model 6.00~16
Tyre Pressure Field Work 100~120(1.0~1.2kgf/c)
Transportation Work 180~200(1.8~2.0kgf/c)
Power Connection 1040
Three B1900 cone Belts.
Heavy Duty Hand Tractors, Walk Behind Tractor 15 HP Walking Tractor with Loncin Engine
Overall Dimension(mm) 2170× 930× 1150
Ground Clearance(mm) 210
Engine ZH1100
Power 15 HP
Wheelbase(mm) 680~1200
Weight(kg) 370
Semiaxis cm 520-600
Weight in use(with oil, water, tools) (kg) 430
Tyre Model 6.00~16
Tyre Pressure Field Work 100~120(1.0~1.2kgf/c)
Transportation Work 180~200(1.8~2.0kgf/c)
Power Connection 1040
Three B1900 cone Belts.
|
Model |
Unit | ty-151E | |
| Structure weight | Without rotary tiller | kg | 238 |
| With rotary tiller | 291 | ||
| Working weight (with rotary tiller) | kg | 331 | |
| Overall dimensions (L*W*H) | mm | 2170x845 x 1150 | |
| Number of blades | PCS | 14 | |
| Rototilling width | mm | 700 | |
| Type of tractor |
|
Single axle, dual-purpose for both traction & drive | |
| Travelling speed | Forward | Km/h | 1.98, 3.08, 4.98, 8.04, 12.49, 20.2 |
| Reverse | 1.53, 6.18 | ||
| Type size |
|
6.00-12 | |
| Wheel track | mm | 680~740(adjustable) | |
| Min. ground clearance | mm | 210 | |
| Min. turning radius | m | 0.71 (without rotary tiller) | |
| Model of engine |
|
190NE | |
| Type of engine |
|
Horizontal 4-stroke | |
| Bore x stroke | mm | 90× 90 | |
| Total displacement | L | 0.573 | |
| Compression ratio |
|
21: 01 | |
| Turing speed of crankshaft | rpm | 2300 | |
| 1-hour rated output | KW/hp | 7.7/10.5 | |
| 12-hour rated output | KW/hp | 7.0/9.5 | |
| Specific fuel consumption | g/kw. h | ≤ 273.4 | |
| Specific lube oil consumption | g/kw. h | ≤ 2.72 | |
| Cooling mode |
|
Condenser (Radiator) | |
| Main farm implements (optional) |
Anti-skid steel wheel Model 100-640 Single-furrow plough Model 1LS-125 Turnover plough Rotary tiller Model MX80D-1 Sprinkler Model 50BPZ-45 Swather/reaper Model 4GL-100 Trailer 7C-0.8 (Standard) |
||
