2CM-1A Potato Planter, Potato Planter for Walking Tractor, Power Tiller
Go back to Catalog: Potato Planter & Digger
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
2CM-1A Potato Planter Series
CM-1 Potato Planter
CM-1 Potato Planter
Product Description:
Technique parameter:
Potato seeder matched with 25~35 horsepower four round tractor necessary uses, have the structure to be compact, the mobility is good, the layout is reasonable, the work is steady, the compatibility is strong, the service is simple and so on, may act according to different local agronomy planter request, the adjustment depth, the row spacing and the distance between plants. Potato seeder is mainly composed of ground-driven wheels, stander, ditcher, seeding device, seed tank and fertilizer tank, etc.
• Potato planter can plant the potato and fertilize at the same time.
• Row spacing and line spacing is adjustable.
• Compact structure, chain transmission.
• Plastic planting cups, in order to protect the seeds.
• Row spacing and line spacing is adjustable.
• Compact structure, chain transmission.
• Plastic planting cups, in order to protect the seeds.
Model | unit | 2CM-1 | 2CM-2 |
Overall weight | kg | 90 | 200 |
Row spacing | cm | 40---75 | 50---85 |
Planting distance | cm | 25---33 | 25---33 |
Productivity | hm2/h | 0.1~0.14 | 0.4---0.6 |
Matched Power | hp | 18 | 20--35 |
