Snow Blade, Tractor Front Snow Blade, Snow Removal, Land Pride
Go back to Catalog: Dozer Blade
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
Snow Blade Series
Front bulldozer features:
* Hydraulic transmission is used,featured with compact structure,flexibility,convenient operation and quick mounting and dismounting.
* It uses hydraulic oil commonly with tractor.The hydraulic elements are standardized,convenient for operation and service.
Front bulldozer application:
* It’s used in removing of Push the soil flat soil with quick speed and high efficiency.
* It’s also used in clearing away or stocking of loose material.
Front bulldozer Specification:
Front bulldozer features:
* Hydraulic transmission is used,featured with compact structure,flexibility,convenient operation and quick mounting and dismounting.
* It uses hydraulic oil commonly with tractor.The hydraulic elements are standardized,convenient for operation and service.
Front bulldozer application:
* It’s used in removing of Push the soil flat soil with quick speed and high efficiency.
* It’s also used in clearing away or stocking of loose material.
Front bulldozer Specification:
| Blade Model | TT150 | TT165 | TT180 | TT200 | |
| Matched Power | Kw(hp) | 14.7~29.4(20~40) | 29.4~44.1(40~60) | 44.1~58.8(60~80) | 58.8~66.2(80~90) |
| Overal Width | mm | 1500 | 1650 | 1800 | 2000 |
| Operation Width | mm | 1500/1300 | 1650/1430 | 1800/1560 | 2000/1800 |
| Blade Angle | (°) | 0/0,16,30 | 0/0,16,30 | 0/0,16,30 | 0/0,16,30 |
| Shoveling Angle | (°) | 60 | 60 | 60 | 60 |
| Weight | kg | 220/300 | 240/320 | 300/360 | 330/400 |
