TS400 Tractor, 40HP 4 Wheel Farm Tractor (TS400)
Go back to Catalog: TS Tractor
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
TS400 Tractor Series
| Model | TS400 Tractor | TS404 Tractor | |
| Drive Type | 4×2 | 4×4 | |
| Engine | |||
| Engine Manufacturer | Jiangsu,Jianghuai | Jiangsu,Jianghuai | |
| Engine Model | JD490T | JD490T | |
| Engine Type | inline,vertical,water-cooled,four-stroke | inline,vertical,water-cooled,four-stroke | |
| Cylinder diameter(mm) | 90 | 90 | |
| Stroke(mm) | 105 | 105 | |
| Max Torque(N·m)/Revolving Speed(rpm) | ≥165/≤1725 | ≥165/≤1725 | |
| Displacement(L) | 2.67 | 2.67 | |
| Fuel Tank Capacity(L) | 51 | 51 | |
| Engine Rated Power (kW/rpm) | 29.4 | 29.4 | |
| Rated Operating Conditions Fuel Consumption Rate(g/kW·h) | ≤245 | ≤245 | |
| Drive Train | |||
| Clutch | Dry,single-stage | Dry,single-stage | |
| Standard PTO speed(rpm) | (540,1000)/(750,1000)/(540,750) | (540,1000)/(750,1000)/(540,750) | |
| Gears | 8F+2R/10F+2R | 8F+2R/10F+2R | |
| Speed range(Km) | 2.17~27.7 | 2.17~27.7 | |
| Steering type | mechanical steering | hydraulic steering | |
| Gear Shift Mode | sliding gear shift | sliding gear shift | |
| Break System | |||
| Service Brake | pedal,mechanical drive,closed shoe type | pedal,mechanical drive,closed shoe type | |
| Parking Brake | locked pedal | locked pedal | |
| Hydraulic System | |||
| Hydraulic Output Flow(L/min) | 30 | 30 | |
| Hydraulic Output Valve | 1 way(optional) | 1 way(optional) | |
| Working Device | |||
| Three-Point Suspension | postposition,Category I | postposition,Category I | |
| Max.Lifting Capacity(kN) | ≥6.62 | ≥6.62 | |
| Tillage Depth Adjustment | draft and position adjustable | draft and position adjustable | |
| General Parameter | |||
| Overall Dimension(L×W×H)mm | With cab | / | / |
| Without cab | 3315×1490×2105 | 3360×1490×2100 | |
| Wheelbase(mm) | 1960 | 1950 | |
| Min. operating weight(kg) | With cab | / | / |
| Without cab | 1630 | 1890 | |
| Min. Ground Clearance(mm) | 485 | 365 | |
| Min.turning radius(mm) | 3200 | 3300 | |
| Maximum Pull(KN) | 7.8 | 12 | |
| Front Tire | 6.0-16 | 7.5-16 | |
| Rear Tire | 11.2-28 | 11.2-28 | |
| Optional Disposition | |||
|
|
hydraulic steering, dual-stage clutch, shuttle gear(creeper gear), paddy tire, swing draw bar, ROPS with canopy, 1 group hydraulic output |
dual-stage clutch, shuttle gear(creeper gear), paddy tire, swing draw bar, rear counter weight, ROPS with canopy, 1 group hydraulic output |
|
