ZL10 Wheel Loader, 1 Ton wheel loader with CE
Go back to Catalog: Wheel Loader
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
ZL10 Wheel Loader Series
| HE TECHNICAL PARAMETERS OF ZL10A CE CERTIFICATE MINI WHEEL LOADER | |||
| Item | Specifications | Item | Specifications |
| Rated loading weight | 1000kg | Operating weight | 2850kg |
| Rated bucket capacity | 0.5m3 | Overall dimensions(LxWxH) | 4750x1500x2530mm |
| Bucket width | 1500mm | Engine model | CHANGCHAI 385 |
| Track base | 1215mm | Engine type |
In-line arrangement, water cooled, three-cycle diesel engine |
| Wheel base | 1985mm | Engine starting mode | Electric |
|
Min. turning radius (outside of rear wheels) |
4200mm | Rated power/Rated speed | 20KW/2200rpm |
| Min. Ground clearance | 250mm | Brake mode |
Four-wheel hydraulic spread-shoed brake |
| Dump height fully raised | 2300mm | Warranty | 12 months after received the goods |
| Reach fully raised | 850mm | Color |
According to the requirements of customers |
| Lifting time | 4S | Tyre type | 8.25-16 |
| Hydraulic cycle time | 8S | Shipping port | Qingdao port, China |
| Max. Tilt angle | 300 | Packing details |
Nude package, 1Unit/20's GP with disassembled cabin, 3Units/40's HQ |
|
Max. Bucket breakout, lift cylinder |
22KN | Delivery time | 15 days after confirm the order |
| Driving mode | Four-wheel drive | Supply ability | 100 units per month |
