ZL28 Wheel Loader, China ZL28 Wheel Loader Manufacturer
Go back to Catalog: Wheel Loader
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
ZL28 Wheel Loader Series
Weichai Huafeng 4108/YTO 4108 engine, 83kw, Torque converter, Hydraulic Joystick, quick hitch, standard bucket, 16/70-24 tires.
Torque converter, Rear Video Camera, manual floating function, Varta battery,heater, 220V engine preheat. warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer.
2. Detailed specification
Weichai Huafeng 4108/YTO 4108 engine, 83kw, Torque converter, Hydraulic Joystick, quick hitch, standard bucket, 16/70-24 tires.
Torque converter, Rear Video Camera, manual floating function, Varta battery,heater, 220V engine preheat. warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer.
2. Detailed specification
| Specification | Overall Weight(Kg) | 6500KG |
| L×W×H(Mm) | 6570x2150x2850 | |
| Rated Bucket Capacity(M3) | 1.2 | |
| Rated Load(Kg) | 2800 | |
| Maximum Dump Height (Mm) | 3500 | |
| Engine | Model |
Weichai Huafeng 4108 YTR4108 |
| Rated Power(Kw) | 83kw | |
| Rated Speed(R/Min) | 2400 | |
|
Transmission System |
Model Of Torque Converter | YJ280 |
| Gear Shift | 2 Gears Ahead,2 Gear Astern | |
| Brake System | Brake Type | Air Assisted Oil Disc On Four Wheel |
| Tyres | Standard Tyres | 16/70-24 or 16/70-24 agricultural tires |
