1BZ Heavy Duty Offset Disc Harrow, Tractor 3 Point Heavy Duty Offset Disc Harrow
Go back to Catalog: Disc Harrow
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
1BZ Heavy Duty Offset Disc Harrow Series
Designed by confidently advanced technology of our company connecting with international technology through many times of experiments, disc harrows are mainly used for middle and large size of tractors, Hp about 55-160. With steady structure and fine effect on hard plain and harrowing wasteland, disc harrows have been popularly exported to many countries and districts. IBZ series hydraulic heavy-offset disk harrows are equipped with hydraulic lifting tires and spring leveling mechanism and designed by international advanced ideas, with using steel structure as the main harrows body. So, this heavy harrows are especially suitable to plough large farmland with the features of durable structure, easy transportation and easy maintenance.
Parameter of Hydraulic Heavy-Offset Disk Harrows
Designed by confidently advanced technology of our company connecting with international technology through many times of experiments, disc harrows are mainly used for middle and large size of tractors, Hp about 55-160. With steady structure and fine effect on hard plain and harrowing wasteland, disc harrows have been popularly exported to many countries and districts. IBZ series hydraulic heavy-offset disk harrows are equipped with hydraulic lifting tires and spring leveling mechanism and designed by international advanced ideas, with using steel structure as the main harrows body. So, this heavy harrows are especially suitable to plough large farmland with the features of durable structure, easy transportation and easy maintenance.
Parameter of Hydraulic Heavy-Offset Disk Harrows
|
Model
|
unit
|
1BZ-1.8
|
1BZ-2.2
|
1BZ-2.5
|
1BZ-3.0
|
1BZ-3.4
|
|
Overall size
|
mm
|
4800*2000*1340
|
4820*2440*1340
|
5320*2880*1340
|
5320*3320*1340
|
5820*3760*1340
|
|
Weight
|
kg
|
1050-1100
|
1250-1300
|
1380-1430
|
1500-1550
|
1650-1700
|
|
Working width
|
m
|
1.8
|
2.2
|
2.5
|
3.0
|
3.4
|
|
Working depth
|
mm
|
200
|
||||
|
Disc space
|
mm
|
230
|
||||
|
Qty. of disc
|
pc
|
16
|
20
|
24
|
28
|
32
|
|
Dia. Of disc
|
mm
|
660
|
||||
|
Ground clearance
|
mm
|
>160
|
||||
|
Productivity
|
ha/h
|
1.1
|
1.3
|
1.4
|
1.7
|
1.9
|
|
Matched power
|
hp
|
44-55
|
50-65
|
55-75
|
60-90
|
65-100
|
|
Linkage
|
|
Trailed
|
||||
|
remarks
|
36、40、48、56slice parameter，See the product parameters form
|
|||||
